Home > Force Inductions > TURBO CHARGERS > CAR > LOTUS > 1990- Lotus ELAN RHB52TW Turbo VD130087 VI78

1990- Lotus ELAN RHB52TW Turbo VD130087 VI78

1990- Lotus ELAN RHB52TW Turbo VD130087 VI78
Item# turbo-car-lotus-TC-VD130087
$1,935.00
Availability: Usually ships the next business day

Product Description


Part NumberVD130087
Previous versionsVA130087, VC130087
OE number8944731580, 8-94473-1580
Year1990-
DescriptionLotus ELAN
V-Spec.VI78
CHRANE920028 (553T-531, NE920031, VA810023)(1000040129) $300.00 NEW IN STOCK, MADE IN USA
Turbo ModelRHB52TW-52002TP15NRBRL3911EZ
Engine4xE1-WT, 4XE1 MT
Displacement1.6L, 1600 CCM, 4 Cylinders
FuelGas
HP167
Angle α (compressor housing)118°
Angle β (turbine housing)32°
Bearing HousingNN133360 (053T-520, NN133362, NN133378, VA810023)(Water Cooled)(1900011199, 1000040129) $82.50 NEW IN STOCK
Turbine WheelNN131502 (223T-515, NN131612, NN161312)(Ind. 52.47 mm, Exd. 43.05 mm, Trm 5.2, 9 Blades)(1100016018) $107.20 NEW IN STOCK
Comp. WheelNN136610 (39T-044)(Ind. 38.53 mm, Exd. 52.19 mm, Trm 4.7, 5+5 Blades, Flatback)(1200020268) $48.16 NEW IN STOCK
Back plateNN133021 (64T-002)(1800016033) $44.50 NEW IN STOCK
Heat shield NumberNN137055 (38T013)(2030016019) $12.25 NEW IN STOCK
Repair KitNN139921 (NN139922)(509T-530, 509T-545)(5000080115) $68.00 NEW IN STOCK
Turbine Housing AR15
ActuatorNH982511
Gasket (turbine inlet)210276 (2445051, Metal)
Gasket (turbine inlet)210276 (123901-18090, 2445051)(Inox Steel) $18.87
Gasket (turbine outlet)210858 (Stainless Steel)
Gasket (oil outlet)210636 (122833)(2445067)(Paper) $3.21
Gasket (oil inlet)1203215 (1203715)(Paper)
ManufacturerIHI

Applications

1990- Lotus ELAN with 4XE1 WT Engine

Core Charge

There is a $400.00 core charge which has been included in the price, it means if you DO NOT have or will not send us the original part, we will not refund the core charge. You will be charged at the time of purchase, and will be fully refunded once your old re-build able core is received.

Warranty

This part comes with ONE YEAR unlimited mileage warranty.
