2004- Iveco Truck HX25 Turbo 3599879

2004- Iveco Truck HX25 Turbo 3599879
Item# turbo-truck-iveco-TC-3599879
$998.00
Availability: Usually ships the next business day

Product Description


Part Number3599879
Previous Version2835000, 2835001, 2835002, 2852507, 2852507R, 2857052, 3599880, 4033587, 4033587H, 4042193
OE number504043175, 504043175R, 504311091
Year2004-
DescriptionIndustrial, Agricultural, Truck
Manufacturer Part Number 3599880, 4033587, 4033587H, 4042193
CHRA3539071 (3539071H)(1153025701, 1153025901)(49189-08010, 49189-09620)(1153025901, 1000020153) $298.00 NEW IN STOCK, MADE IN USA
Turbo ModelHX25, HX25-TB11K/A11CXL
EngineNEF
Engine ManufacturerIveco
Angle α (compressor housing)175°
Angle β (turbine housing)360°
Bearing Housing49189-26400 (Oil Cooled)(1153025450, 1900011200E) NEW IN STOCK
Turbine Wheel49189-30100 (Ind. 51.96 mm, Exd. 45.67 mm, Trm 8.5, 12 Blades)(1153025435, 1100030028) $90.00 NEW IN STOCK
Comp. Wheel(Ind. 38.76 mm, Exd. 55.88 mm, Trm 6.35, 16+6 blades, Superback)(1153025400, 1200016491) $183.02 NEW IN STOCK
Back plate49135-00044 (S/Back)(1153025300, 1800016016) $15.94 NEW IN STOCK
Heat shield Number49183-19300 (11530253408, 2030016049) $14.64 NEW IN STOCK
Repair Kit(1153025751, 5000050007) $69.00 NEW IN STOCK
Gasket (turbine inlet)210218 (Stainless Steel) $24.90
Gasket turbine outlet210889 (Stainless Steel) $39.90
Gasket oil outlet210243 (Gasket paper) $2.00
Gasket Kit 215255 (2090505019)
ManufacturerHOLSET

Applications

2004- Iveco Industrial, Agricultural, Truck NEF

Will also fit CASE 440,440ct,450,450ct, 465 Tier 2 and Tier 3 engines.

Fits New Holland Equipment L190, C190, U80 with Tier 3 engines

Core Charge

There is a $100.00 core charge which has been included in the price, it means if you DO NOT have or will not send us the original part, we will not refund the core charge. You will be charged at the time of purchase, and will be fully refunded once your old re-build able core is received.

Warranty

This part comes with ONE YEAR unlimited mileage warranty.
