Part Number | 53299887115 |
Previous versions | 5329-988-7115, 5329 988 7115 |
OE number | 51.09100-7750, 51091007750, 51.09100-7923, 51091007923 |
Year | 2005-12 |
Description | Truck |
Manufacturer Part Number | 53299707115, 5329-970-7115, 5329 970 7115 |
CHRA | N/A |
Turbo Model | K29-3775XYCKB17.20GDHWD |
Engine | D2066LF |
Displacement | 10.52L, 10520 ccm |
Power kW / hp | 353/481 |
RPM | 1900 |
Fuel | Diesel |
Angle α (compressor housing) | 297° |
Angle β (turbine housing) | 265° |
Repair Kit | 53317110005 |
Turbine Housing AR | 71mm C/W, 17cm2 |
COMP. WHEEL O.D. | 3.70 |
COMP. WHEEL INDUCER DIA | 2.79 |
COMP. WHEEL INDUCER DIA.(MM) | 70.93 |
TURBINE WHEEL O.D. | 3.23 |
TURBINE WHEEL O.D. (MM) | 82 |
TURBINE WHEEL EXDUCER | 2.80 |
TURBINE WHEEL EXDUCER (MM) | 71.00 |
TURBINE A/R | 17 cm |
NOTE | Intercooler |
Replaced By | 53299887120 |
Manufacturer | Borg Warner - 3K - Schwitzer BWTS DE |
2005-12 Man Truck with D2066LF Engine There is a $300.00 core charge which has been included in the price, it means if you DO NOT have or will not send us the original part, we will not refund the core charge. You will be charged at the time of purchase, and will be fully refunded once your old re-build able core is received. This part comes with ONE YEAR unlimited mileage warranty.Applications
