1997-02 Renault Earth Moving S200 Turbo 316184

1997-02 Renault Earth Moving S200 Turbo 316184
Item# turbo-earth-moving-renault-TC-S2007536-315737
$1,250.00
Availability: Usually ships the next business day

Product Description


Part Number 316184
OE number 5010339464
Year1997-02
DescriptionEarth Moving
Manufacturer Part Number315737
CHRA316161 $837.35
Turbo Model S200
Engine MIDR060226M71 (US94)
Displacement 6.18L, 6180 ccm
KW142/190
FuelDiesel
Angle α (compressor housing)270°
Angle β (turbine housing)180°
Bearing Housing167994
Turbine Wheel168431 $476.50
Comp. Wheel169620
Back plate167744 $83.38
Heat shield Number167997 $44.74
Repair Kit318383 $97.60
Turbine Housing316158/319070 $275.31
Compressor Cover314820
Gasket (inlet) twin entry196570 $19.59
Gasket (turbine inlet) single entry312617 $8.20
Gasket (oil outlet)311496 $3.32
Gasket (oil inlet)147837 $4.48
ManufacturerBorg Warner - 3K - Schwitzer

Applications

1997-02 Renault Earth Moving Phase 2 with MIDR060226M71 (US94) Engine

Core Charge

There is a $300.00 core charge which has been included in the price, it means if you DO NOT have or will not send us the original part, we will not refund the core charge. You will be charged at the time of purchase, and will be fully refunded once your old re-build able core is received.

Warranty

This part comes with ONE YEAR unlimited mileage warranty.
