Caterpillar Industrial Engine, Earth Moving 4HD-857 Turbo 155407

Caterpillar Industrial Engine, Earth Moving 4HD-857 Turbo 155407
Item# turbo-earth-moving-cat-TC-155407
$3,784.49
Availability: Usually ships the next business day

Product Description


Part Number155407
OE number2P1721, 2P-1721
DescriptionIndustrial Engine Earth Moving R.H.
Interchangeable CHRA 147713 (310145, 0R5922, 6N1617, 8S6009, 178137, 478137, 151192, 1P1190, 4N4041) $1542.84 NEW IN STOCK
CHRA157702 (310145, 0R5883, 4N4041, 6N8658, 178141) $1,708.72 NEW IN STOCK
Turbo Model 4HD-857
Industrial Engine D349
Serial No. 61P1 to 61P471 inclusive
Fuel Diesel
Bearing Housing137568 (4N4042, 0R5399, 2S1309, 9M9929)(Oil Cooled) $528.14 NEW IN STOCK
Turbine Wheel181480 (159750)(0R5390, 7S7759, 159750, 0R5389, 2S1530, 9M9933)(Ind. 93.2 mm, Exd. 112-113.2 mm, Trm 16.85, 13 Blades) $507.25 NEW IN STOCK
Comp. Wheel140922 (139398)(5S3975)(Ind. 78.8 mm, Exd. 122. mm, Trm 7.56, 7+7 Blades, Superback) $369.16 NEW IN STOCK
Back plate140050 (9M495) $437.90 NEW IN STOCK
Heat shield Number139053 (2S1305, 9M9934)(18494, 49160-22501, 144244-0000)(1250404300) $73.38 NEW IN STOCK
Repair Kit318357 (183214, 181836)(1250404751, 1250404753) $160.90 NEW IN STOCK
Nozzle Ring147120 (5S3472) $262.49
Shim .127 mm(.005 in.) thick125648 (15189, 8M7167, 49160-42400, 144054-0000)(1250404250) $6.29 NEW IN STOCK $6.29
Shim .127 mm(.005 in.) thick15190 (125649, 8M7168, 144055-0000, 49160-42500)(1250404251) $6.29 NEW IN STOCK
Shim .254 mm(.010 in.) thick15191 (125650, 8M7169, 49160-42600, 144056-0000)(1250404252) $6.29 NEW IN STOCK
Turbine Housing(9M9937)
Compressor Cover1P5458 $419.11
Gasket (turbine inlet)409038-0000 (132040, 202873, 205396, 3500683, 1S4295, 9749, 210017-0000)(1900000003) $15.49
Gasket oil inlet129119 (201049, 9737, 1S6595, 210019-0000, 409266-0003, 3819900)(1900000035) $3.22
Gasket (oil outlet)210018 (201048, 210018-0000, 1S4810, 409267-0002, 3709738, 3500682, 3519763, 9738, 9988, 129120)(1900000025) $3.22
NOTER.H.
ManufacturerBorg Warner - 3K - Schwitzer

Use 182824

Applications

Caterpillar Industrial Engine, Earth Moving with D349 Engine

Core Charge

There is a $500.00 core charge which has been included in the price, it means if you DO NOT have or will not send us the original part, we will not refund the core charge. You will be charged at the time of purchase, and will be fully refunded once your old re-build able core is received.

Warranty

This part comes with ONE YEAR unlimited mileage warranty.
