Caterpillar 966D Loader 4LE-302 Turbo 184662

Caterpillar 966D Loader 4LE-302 Turbo 184662
Item# turbo-earth-moving-cat-TC-184662
$1,239.99
Availability: Usually ships the next business day

Product Description


Part Number 184662
OE number 8N1441, 0R5803
Description Earth Moving 966D Loader RH
CHRA180293 ( Use 178205, 310122, 4N9534, 0R5893, 4N3753, 6N6521) $857.01 NEW IN STOCK
Turbo Model4LE302, E-302
Engine D333C, 3306
FuelDiesel
Loader 966D
S/N8Z1731 TO 8Z3841 Inclusive, 99Y00001-05314
Bearing Housing159505 $183.32 (5S4543, 0R5406, 4N9540)(408495-0009, AR73129, 4062624) $183.32 NEW IN STOCK
Turbine Wheel184409 (0R5391, 5S4544, 8S4989)(Ind. 72.1 mm, Exd. 91. mm, 6+6) $381.88 NEW IN STOCK
Comp. Wheel159608 (4N3754, 9N2378, 9N0145)(Ind. 62.5 mm, Exd 93.7 mm, Trm 302, 6+6)(1250040400) $325.44 NEW IN STOCK
Back plate197651 (51135, 142066, 5S4556, 52321523000, 52321523001, 49162-22500, 1250403300, 143044-0000) $52.04 NEW IN STOCK
Heat shield Number188086 (148046, 4N9556, 8S9221) $61.82 NEW IN STOCK
Repair Kit318350 (6N7245, 2W0725, 183211) (1250040751) $119.21 NEW IN STOCK
Turbine Housing8S9228 $454.34
Compressor Cover6N7697 $425.95
Gasket (turbine inlet)132040 (1S4295, 210087-0000, 409377-0000)129119 (201049, 210019-0000, 409266-0003, 409266-0004) $17.21
Gasket (oil outlet)210018 (129120) $8.22
Gasket (oil inlet)129119 (201049, 210019-0000, 409266-0003, 409266-0004) $4.22
ManufacturerBorg Warner - 3K - Schwitzer

Applications

Caterpillar Earth Moving with 3306 Engine

Core Charge

There is a $200.00 core charge which has been included in the price, it means if you DO NOT have or will not send us the original part, we will not refund the core charge. You will be charged at the time of purchase, and will be fully refunded once your old re-build able core is received.

Warranty

This part comes with ONE YEAR unlimited mileage warranty.
