Caterpillar Industrial BTL85, BTL8505 Turbo 471168-0001

Caterpillar Industrial BTL85, BTL8505 Turbo 471168-0001
Item# turbo-industrial-caterpillar-TC-4711680001
$2,965.34
Availability: Usually ships the next business day

Product Description


Part Number471168-5001S
Previous Version471168-0001, 471168-1, 471168-2, 471168-9001S, 471168-9002S, 471168-5002S , 471168-0002
OE Number204-5462, 2045462, 10R0430, 10R-0430, 0R7128, 1323647, 0R-7128, 132-3647
DescriptionIndustrial, Truck
CHRA449109-0013 (449109-5013S, 449109-0007, 710270-0034, 1488167, 148-8167, 0R7129, 135-5317) $1,980.94
CHRA Interchange449109-0007 (135-5317, 2071333, 207-1333)
Turbo ModelBTL85, BTL8505
Engine Model3516, 3516B
Engine Manufacturer Caterpillar
New Part Number1323647, 132-3647
Reman Part Number0R7128, 10R0430
Engine Speed69000
Fuel Diesel
Displacement6900 ccm, 16V Cylinders
Machine Engine3516, 3516B
Excavator5230B
Off-Highway Truck785C, 789C
S/N7TR634-1321, 7TR1-1321, 4HZ00001-UP, 2BW00001-UP, 5AZ00001-UP
Bearing Housing449159-0005 (Water-Cooled) $413.58 NEW IN STOCK
Turbine Wheel449236-0001 (44567-0005)(Ind. 101.05 mm, Exd. 110.24 mm, 11 Blades, Boreless) $683.40 NEW IN STOCK
Comp. Wheel449207-0012 (Ind. 76. mm, Exd. 117.42 mm, 7+7 Blades, Boreless) $283.64 NEW IN STOCK
Back plate448797-0011 $284.86 NEW IN STOCK
Heat Shield / Shroud441096-0001 (441097-0001) $16.12 NEW IN STOCK
Repair Kit707899-0001 (468416-0000)(1101090750, 1101090755) (1N3593, 1089342) $92.40 NEW IN STOCK
Turbine Housing441122-0122 (1262757, 2586589) $590.00
Compressor Cover442892-0038 (1355300) $613.39
Turbine Housing AR0.96
Gasket (turbine inlet) 409038-0001 (1215736, 210835-0000, 9749)(Inox Steel) $14.02
Gasket oil inlet210161 (128300-1323, Gasket paper) $2.00
Gasket (oil outlet)210172 (Paper) $2.00
Gasket (water inlet and outlet)210021 (409037-0000, 210021-0000, 311496, 413671-0000, 3519807)(Paper) $4.48
NOTEPartially restricted
New listed$6,764.63
ManufacturerHoneywell-Garrett

Applications

Caterpillar Industrial Engines and Power Units with 3516 Engine

Core Charge

There is a $500.00 core charge which has been included in the price, it means if you DO NOT have or will not send us the original part, we will not refund the core charge. You will be charged at the time of purchase, and will be fully refunded once your old re-build able core is received.

Warranty

This part comes with ONE YEAR unlimited mileage warranty.
