Home > Force Inductions > TURBO CHARGERS > MARINE > CUMMINS > 2002-06 Cummins Marine C Series HX55WM Turbo 4041656

2002-06 Cummins Marine C Series HX55WM Turbo 4041656

2002-06 Cummins Marine C Series HX55WM Turbo 4041656
Item# turbo-marine-cummins-TC-4041656
$2,998.00
Availability: Usually ships the next business day

Product Description


Part Number4041656
Previous Part Number3598908, 4036776, 4041656, 4041739, 4041739H
OE number4089942, 4089942NX, 4089942RX, 4955232, 495523200, 4955232NX, 4955232RX
DescriptionMarine
CHRA4031411 (4031411H, 403141100) $650.00 NEW IN STOCK
Turbo ModelHX55WM, HX55WM-C98K72RU/C86L90PJ14S-W
Manufacturer Part Number3598908, 4041739
EnginePegasus, C Series
Engine ManufacturerCummins
NSN #2950-01-565-8973, 2950015658973
Displacement8.9L, 8900 ccm
KW325/400 HP
Code4041739
Fuel Diesel
Angle α (compressor housing)320°
Angle β (turbine housing) 310°
Bearing Housing 4027817 (3535704,3535575)(Oil Cooled) $119.25 NEW IN STOCK
Turbine Wheel3535983 (353598300)(Ind. 85.8 mm, Exd. 76.95 mm, Trm 12.85, 12 Blades)(1153055436, 1100016122B) $198.00 NEW IN STOCK
Comp. Wheel4035887 (3596135, 4036317, 4035887H)(Ind. 71. mm, Exd. 99.01 mm, Trm 51, 7+7 Blades, Billet) $68.00 NEW IN STOCK
Back plate3528096 (352809600)(1153055300, 1800016024) $21.48 NEW IN STOCK
Heat shield Number3529846 (3533038)(353303800, 352984600)(1153055340) $13.22 NEW IN STOCK
Repair Kit 3580762 (3575181)(358076200, 357518100)(1153055750, 5000020023) $88.00 NEW IN STOCK
Turbine Housing (Water Cooled)35396073
Compressor Cover4036634
Actuator4031412 (3595025, 3595085) $157.48
Gasket Kit3800279 (380027900)(2090505445) $39.00 NEW IN STOCK
ManufacturerHOLSET
ConditionRebuilt

Applications

2002-06 Cummins Marine Pegasus with Pegasus Engine

Core Charge

There is a $500.00 core charge which has been included in the price, it means if you DO NOT have or will not send us the original part, we will not refund the core charge. You will be charged at the time of purchase, and will be fully refunded once your old re-build able core is received.

Warranty

This part comes with ONE YEAR unlimited mileage warranty.
