Isuzu, Sumitomo Earth Moving RHC7 Turbo VB250074 CIAF

Isuzu, Sumitomo Earth Moving RHC7 Turbo VB250074 CIAF
Item# turbo-earth-moving-hitachi-TC-VB250074
$1,890.00
Availability: Usually ships the next business day

Product Description


Part NumberVB250074
Previous versionsVA250074, VC250074, VD250074
V-SPEC.CIAF
Previous Version114400-2961, 1144002961, 7T545, 1-14400-2961, 1-14400-296-1, 7T-545, C71CND-S0074B, C71CND-S0074G, C71CNDS0074B, C71CNDS0074G
DescriptionEarth Moving, Link Belt
CHRAVA860035 (NZ853750) $450.00 NEW IN STOCK
Turbo ModelRHC7-13005HQ30NFBRL557A
Engine6BG1TPC-03
Displacement 6 Cylinders
FuelDiesel
Angle α (compressor housing) 180°
Angle β (turbine housing) 310°
Bearing Housing NH173375 (Oil Cooled)
Turbine Wheel NH171671
Comp. Wheel NH175104 (Ind. 53.91 mm, Exd. 75.95 mm, Trm 2.86, 5+5 Blades, Superback) $145.00 NEW IN STOCK
Back plate NH172501
Heat shield NumberNH178265
Repair Kit NH179859 $99.00 NEW IN STOCK
Turbine Housing NH178299
Compressor Cover NH174402
Turbine Housing AR30
ManufacturerIHI

Applications

Isuzu Earth Moving, Truck with 6BG1TPC-03 Engine

Sumitomo SH2200 with 6BG1T Engine

Core Charge

There is a $200.00 core charge which has been included in the price, it means if you DO NOT have or will not send us the original part, we will not refund the core charge. You will be charged at the time of purchase, and will be fully refunded once your old re-build able core is received.

Warranty

This part comes with ONE YEAR unlimited mileage warranty.
