Caterpillar Industrial Engine, Marine TW6146 Turbo 466096-0005

Caterpillar Industrial Engine, Marine TW6146 Turbo 466096-0005
Item# turbo-industrial-caterpillar-TC-4660960005
$2,899.71
Availability: Usually ships the next business day

Product Description


Part Number466096-5005S
Previous Version466096-0005, 466096-5, 471180-0001
OE Number127-4516, 1274516, 7C4470
Description Marine Engine , Industrial Engine
CHRA449530-0010 (409043-0088, 449530-5010, 449530-9010, 4495300010, 4495305010)(0R7178, 136-4402, 1364402) $1,210.27
Turbo ModelTW6146
Engine Model3412 DITAJWAC GS
Engine Manufacturer Caterpillar
Displacement 34.5L, 34500 ccm, 8V Cylinders
KW860 HP
FuelDiesel
Industrial EngineG3508, G3512
S/N4KC163-UP, 2JF1-183; 2JF325-342, 9TG54-127
Bearing Housing449072-0001 (408495-0028, 408495-0009, 408495-0010)(Oil Cooled)(0R5404, 160025, 9N2035)(1101672450) $303.80 NEW IN STOCK
Turbine Wheel449587-0005 (408493-0015, 408493-0006)(6N8486)(Ind. 89. mm, Exd. 70. mm, 11 Blades) $276.00 NEW IN STOCK
Comp. Wheel409033-0011 (447033-0010)(1W8420)(Ind. 63.78 mm, Exd. 94.02 mm, 6+6 Blades, Billet) $240.59 NEW IN STOCK
Back plate 447241-0001 (408487-0017, 408487-0032, 408487-0021)(4P3820, 8N0819, 331640848717) $205.82 NEW IN STOCK
Heat shield Number410113-0002 (407967-0003, 407657-0004, 409794-0000)(9N2037, 9N3701, 8925757)(1101680340, 2030016098) $22.00 NEW IN STOCK
Repair Kit468103-0000 (468173-0000, 468267-0010, 312325, 188400-0000)(3545824, 2W0715)(1101085750, 5000010008) $97.20 NEW IN STOCK
Turbine Housing (Water Cooled)409339-0216 (409133-0141)(159-3764, 6N9906) $1,308.90
Compressor Cover 409603-0015 (2W3557, 2458446) $576.50
Turbine Housing AR 1.37
Gasket (turbine inlet)409038-0001 (132040, 7M7273)132040 (9749, 1S4295, 202873, 205396, 3500683, 210017-0000, 409038-0000, 52231083002)(1900000003) $13.20
Gasket oil inlet129119 (201049, 9737, 1S6595, 210019-0000, 409266-0003, 3819900)(1900000035) $4.38
Gasket (oil outlet)210018 (129120, 210018-0000, 409267-0002, 3709738, 3500682, 201048, 1S4810, 9988, 9738, 3519763) (1900000025) $4.38
Plugs185174 (1B5174, 4N0932) $6.71
Listed$4991.76
Replaced By 471180-0001
ManufacturerHoneywell-Garrett

Applications

Caterpillar Industrial Engine Gen Set with 3412 DITAJWAC GS Engine

Core Charge

There is a $500.00 core charge which has been included in the price, it means if you DO NOT have or will not send us the original part, we will not refund the core charge. You will be charged at the time of purchase, and will be fully refunded once your old re-build able core is received.

Warranty

This part comes with ONE YEAR unlimited mileage warranty.
