For Phone order call 818-506-8005 1-877-42TURBO(TOLL Free)Volvo BM (VME) L90B, L90C Loader T04E10 Turbo 466742-0014
Product Description
| Part Number | 466742-0014 |
| Previous Version | 466742-0014 |
| OE number | 1103390, 11032959, 4881600 |
| Description | L90B, L90C Earth Moving |
| CHRA | 447450-0114 (447450-5114S) $550.00 NEW IN STOCK, MADE IN USA |
| Turbo Model | T04E10 |
| Engine | TD63KBE, TD61GB |
| Model | Volvo BM (VME) L90B Loader, L90B/C |
| Displacement | 5.48L, 5480/6720 ccm, 6 Cylinders |
| Fuel | Diesel |
| Angle α (compressor housing) | 326° |
| Angle β (turbine housing) | 315° |
| Bearing Housing | 430027-0025 (430027-0022, 430027-0048,186879, 186881)(1100030450)(Oil Cooled) $55.20 NEW IN STOCK |
| Turbine Wheel | 446905-0004 (Ind. 57.65 mm, Exd. 73. mm, Trm 62, 11 Blades) $135.00 NEW IN STOCK |
| Comp. Wheel | 442293-0019 (Ind. 47.35 mm, Exd. 75. mm, Trm 40, 6+6 Blades) $89.50 NEW IN STOCK |
| Back plate | 408045-0031 (408045-0030, 408045-0038, 408045-0039, 408045-0061, 408045-0019) (ME078204) $30.87 NEW ON STOCK |
| Heat shield Number | 409299-0001 (409299-0000)(311943, 7N0012, 3524773B) $29.50 NEW IN STOCK |
| Repair Kit | 468265-0000 (1100040760) $69.50 NEW IN STOCK |
| Turbine Housing | 410424-0102 |
| Compressor Cover | 443219-0003 |
| Turbine Housing AR | 0.58 |
| Gasket (turbine inlet) | 409039-0000 (409039-0001, 210019, 2405022)(1900000006)(Inox Steel) $13.52 |
| Gasket (turbine outlet) | 409196-0001 (210226)(Stainless Steel) $29.00 |
| Gasket oil inlet | 210021 (148062, 311496, 3519807, 413671-0000, 409037-0000)(1900000027) $3.32 |
| Gasket (oil outlet) | 210023 (210023-0000, 147837, 210021, 215234, 55739, 3709737, 3500681, 3519762, 409266-0001, 409036-0000, 409026-0001, 52231586500)(1900000037) $4.48 |
| Manufacturer | Honeywell-Garrett |
Interchangeable with 466742-0006 but changes the orientation
Volvo Earth Moving L90B, L90C Loader TD63KBE, TD61GB There is a $300.00 core charge which has been included in the price, it means if you DO NOT have or will not send us the original part, we will not refund the core charge. You will be charged at the time of purchase, and will be fully refunded once your old re-build able core is received. This part comes with ONE YEAR unlimited mileage warranty.Applications
Core Charge
Warranty
